VAV – Pressure Independent– Round to Square

DESCRIPTION:

• Unit has one primary circular air inlet, one rectangular discharge outlet to the room.
• Capacities range from 40-4000 CFM in 6 sizes.
• Units are tested by ETL Intertek in accordance with AHRI Standards 880-2011, “Performance Rating of Air Terminals” and ASHRAE 130-2008, “Methods of Testing Air Terminal Units”.
• Factory calibrated to job requirements.
• Equipped with high quality multi-point differential pressure flow grid for accurate airflow measurement.
• NEMA1 enclosure control box for control mounting.
• Damper edge is sealed with foam gasket to prevent air leakage. The damper shaft is made of solid G.I. rotating in low friction, self lubricating permanently impregnated brass bearings.
• TDF flange on all four sides of rectangular discharge as standard. Inlet connection bead offers a means for secure flex duct connections.
• Sturdy construction and low noise generating capacity to obtain required NC without compromising performance. Manufactured to ensure long and maintenance free service.
• On/off, modulating DC controls 0 to 10V having options of state of the art DDC controls with in built BACnet for BMS compatibility. Belimo/KMC control/Neptronic or controls of customer choice available.
• Integral sound attenuator provides excellent noise control, additional sound attenuator can be provided.
• Casing construction meets SMACNA standards and provides excellent strength and rigidity. Thoroughly sealed to prevent air leakage.
• Interior surface is acoustically and thermally lined with 9mm Nitrile Rubber
