Heavy Duty Louvre

DESCRIPTION:

• Constructed of heavy duty frame and horizontal heavy duty blade assembly made of high quality extruded aluminium profile with the advantages of durability and corrosion resistance.
• Designed to provide more than 65% effective pressure area thereby having lesser pressure drop.
• Used in heavy duty applications that require extremely sturdy construction to withstand heavy storms.
• Louver blades are fixed to the main frame using screws and riveted to the mullions for bigger sizes to have better rigidity.
• Louver blades are specially designed with two stage baffles for excellent rain water penetration.
• Weather resistant structure with blades inclined at an angle of 45 degree to protect against rain water penetration.
• Multiple sections will be assembled as per request.
